Fasteners for Composite Panels
Ashfix Fasteners full OEM approval for Composite Panels in Carbon Steel and Stainless Steel, hexagon and coloured headed fasteners are available from stock.
Technical Information
All Available in Carbon Steel AND Stainless Steel with Bi-Hex Coloured Heads
| CODE |
DIAMETER X LENGTH
|
BUILD UP RANGE MIN |
BUILD UP RANGE MAX |
| CPLS65 | 5.5/6.7X65 | 33mm | 50mm |
| CPLS75 | 5.5/6.7X75 | 35mm | 60mm |
| CPLS85 | 5.5/6.7X85 | 45mm | 70mm |
| CPLS115 | 5.5X6.7X115 | 55mm | 100mm |
| CPLS135 | 5.5X6.7X135 | 75mm | 120mm |
| CPLS150 | 5.5X6.7X150 | 90mm | 135mm |
| CPLS175 | 5.5X6.7X175 | 115mm | 160mm |
|
CPHS245* |
5.5/6.7X245 | 155mm | 220mm |
| * Not available in 11mm Bi-Hex head |
| CODE |
DIAMETER X LENGTH
|
BUILD UP RANGE MIN |
BUILD UP RANGE MAX |
| CPHS85 | 5.5/6.7X85 | 40mm | 62mm |
| CPHS105 | 5.5/6.7X105 | 45mm | 82mm |
| CPHS125 | 5.5/6.7X125 | 55mm | 82mm |
| CPHS150 | 5.5/6.7X150 | 80mm | 127mm |
| CPHS185 | 5.5/6.7X185 | 115mm | 162mm |
|
CPHS245* |
5.5/6.7X245 | 155mm | 220mm |
| * Not available in 11mm Bi-Hex head |
All Available in Carbon Steel AND Stainless Steel
|
|
